20 Ton Battery Power Rail Transfer Cart Exported Australia
Product Information:
Model: KPX
Power: Battery
Capacity: 20T
Table Size: 5000*5000*600mm
Running Speed: 0-20m/min
Rail Type: P24
Product Brief
Order:
1 set battery power rail transfer cart was shipped to Australia from Qingdao port, our Australia client use this battery power rail transfer cart for tunnel site to transfer these arch lining formwork components, precast decks,heavy reinforcements, planks Square formworks, etc. Due to specialized requirement of the widths 5000mm, considering the capacity, the transfer cart will move on the three pcs steel rails with 6 pcs rail wheels.
What' s more, considering the transportation cost, we suggested that the rail transfer cart could be disassembled so that it can be shipped on a 20’ container. The rail transfer cart will be fixed together by bolt after reach to our customers' site.
Product Parameters:
This electric powered rail transfer cart has no time restrictions and can be used around the clock. The platform measures approximately 5000 x 4000 x 500 mm and is controlled by a wireless remote control and a wired handle, facilitating operator control at varying distances.
The rail transfer cart utilizes a box-girder frame and cast steel wheels, ensuring stability, durability, and a strong load capacity. Depending on customer requirements, it can reach a maximum load of 80 tons. Its high temperature resistance makes it suitable for a wide range of harsh environments.
Advantage:
1. Customized manufacture as per our customers’ working site
2. Free provide material handling solution once received your inquiry
3. Low cost with high using frequency
4. Battery powered, which makes the transfer cart more convenient compared with cable powered.
5. Hand pendant and remote control operated, reduce the workers’ operation cost
6. Environmental compared the forklift
7. Free Provide Rail installation and construction drawings
Product Information:
Model: KPX
Capacity: 20T
Table Size: 5000*5000*600mm
Running Speed: 0-20m/min
Power Supply: Battery Drive
Rail Type: P24
Charger: Intelligent charger to protect the battery
Safe Device: Sound and light alarm, dead man stop, E-stop, low battery alarm,buffer, etc.
Operation Type: Operation Handle + Remote control
Customized is supported
