Military-Grade Customized Heavy Duty AGVs: Scenario Based Solutions

Automated Guided Vehicles (AGVs) are core automated transportation equipment in the current industrial logistics field. Leveraging their unmanned and highly efficient transportation advantages, they are widely used in manufacturing, warehousing, and special operations scenarios.

Trackless Omnidirectional Motion

• Unlike standardized transportation equipment, AGVs can be customized in all dimensions, from size and load capacity to platform structure, functional modules, and safety devices, according to the user's actual needs.
• High strength cast steel spliced frame, equipped with a steering wheel drive system capable of 360 degrees free rotation, allows the equipment to move flexibly on hard, flat surfaces without the need for tracks, adapting to complex routes such as narrow passages.
• Lithium battery power, coupled with a smart charger, ensures long-lasting operation. Multiple safety features, including audible and visual warning lights and optional safety edges and laser sensors, provide comprehensive protection, adapting to the specific operational requirements of various industries.

Taking a military factory's outdoor container instrument transport project as an example, Newld specially designed this customized AGV to meet its unique working conditions:

Application Environment and Requirements Analysis

Military-grade outdoor transport requires equipment with extremely high structural stability and sealing capabilities, and it must achieve centimeter-level seamless docking with the container equipment.

Customized Design Implementation

• Structure and Power: Based on the dimensions of the workpieces to be transported, the overall AGV dimensions are set at 3000x2000x700mm. It uses a cast steel frame combined with four-wheel drive rubber wheels,and has a load capacity of up to 1 ton.
• Sealed Platform and Precise Positioning: The platform is designed as a fully sealed cabin structure, effectively protecting the high precision container instruments inside from external environmental influences. Employing a mature and reliable magnetic strip navigation method, precise movement along the set path is ensured.
• Self-stabilizing docking mechanism: A screw-lifting support system is specially installed at each of the four corners of the AGV. When the vehicle reaches the designated docking position, the four corner screws rise and secure it, eliminating slight swaying caused by tire elasticity and ensuring absolute stability during the docking process.

With its comprehensive customization capabilities and core engineering technology, customized AGVs are breaking through the limitations of conventional industrial scenarios, providing safe and efficient intelligent manufacturing support for automated material handling in high precision and specialized industries.
